Features & Advantages
- Linear-Motor-Free Piston System (one moving part - the piston)
- Vibration Isolation Assembly
- Oil-Free Operation
- Self-Cooling Design
- Compact Integrated Design
- Low Noise Level
Description
The Linear-Motor-Driven Free Piston System (Pat.) has an internal piston inside the cylinder which is driven by an electro-magnet and spring system controlled by the mains alternating current. The pump is quiet, vibration free and offers the advantages of easy maintenance and a long operating life. The net result is there are no diaphragms to burst, therefore, no sudden failures occur due to rubber fatigue or over pressure.
| Flow Rate at Rated Pressure | Rated Pressure | Max Pressure | Power |
| Litres Per Min | Bar (ft head) | Bar (ft head) | Watts @ 50 Hz |
| 60 | 0.15 (4.26) | 0.2 (5.12) | 64 |
| 80 | 0.15 (4.26) | 0.2 (5.12) | 86 |
| 120 | 0.18 (5.12) | 0.3 (8.54) | 130 |
| 200 | 0.20 (5.68) | 0.3 (8.54) | 215 |
